Standard Range of Flowwrappers

JE - 5620S-C
Horizontal Flow Wrapping  Machine
(Stainless steel construction)


The JOIE’s Euro-series mechanical Flow Wrapper, Design with 8 sets of Data memory,  4.7” MMI Touch Panel and PLC control,  mounted with Tension Control Dancing Roller, Top Brush Belt and smart Mark Registration, Furthermore, it has a Over Load protection device for end sealing jaws , is a  high Quality and reliable performance Form – Fill – seal machine.  The operation, size change over and maintenance are very quick and easy..


Optional Accessories..
* Date Coder
* End seal Gusset device
* Transfer belt conveyor between center sealer & end sealer
* Center Seal pre heating device.
* Various type of Auto Feeding system

Application.
A wide range wrapping applications, such as: Chocolate, Bakery products, Biscuits, Tissue and Wet wipes, Healthcare products, Hard ware and Frozen foods---etc.

Specifications.
Model: JE-5620-C JE-5920-C
Capacity: 15-170 bags/min 15-120 bags/min
Max. Film Width: 470 mm 610 mm
Max Products W: 195 mm 265 mm
Max. Products H: 60 mm 100 mm
Power required:

3.75 KW at 220 Volt -  single phase

Net Weight: (Approx.) 900 kg 1000 kg
